Linxon Leak Detection

The LINXON LX218 leak detector impresses with its powerful and reliable technology combined with low investment costs.

Integrated INFICON components enable first-class performance for absolute measurement accuracy at outstanding speed. The simple navigation and robust construction make the LX218 leak detector the ideal choice for companies in a wide range of industries. The helium leak detector has a start-up time of less than three minutes and offers a fast leak test and reaction time. A further advantage: With its vacuum mode and sniffing option, it is perfectly suited for efficient leak localization and leak size determination.

OUTSTANDING PERFORMANCE AT A GREAT PRICE


The high-performance LINXON LX218 leak detector features reliable technology together with low investment costs. With proven components produced in high volume by global market leader INFICON and lean distribution structures, top-quality performance is possible at a competitive price.

Leak detection is easier than ever before with the LX218's simple installation and operation. The high suction capacity of the LX218 results in extremely short testing times. This increases your productivity with simultaneous cost efficiency.

Linxon LX218
LINXON LX218 Advantage:

  • Competitive price thanks to standard components and direct distribution channels
  • Highest degree of availability and reliability, even after long periods of use, with proven vacuum technology components such as mass spectrometers, pumps and valves
  • Very short measuring times due to high suction capacity
  • Detection of the smallest leaks, even in environments contaminated by helium, with an intelligent stainless steel vacuum system
  • The highest quality in your production or service application guaranteed by high-precision INFICON measuring technology
  • Easy operation and installation, with no training required
  • Robust and versatile, it can be used even in the harshest production environments

Diaphragm Pump
Diaphragm Pump
For oil-free systems and processes.
Oil-sealed rotary vane pump
Oil-sealed rotary vane pump
For General Industrial application, where
robustness is required.
Module
Module
Without forepump, for easy and affordable
system integration.


Simple operation, flexible system integration and leak testing methods

The LINXON LX218 leak detector offers many advantages for particularly fast and easy vacuum leak testing. With its robust, modular design and additional accessories, the LX218 offers the greatest flexibility and reliability.


Easy-to-use display
Easy-to-use display
It’s easy to operate and features a large
graphic display for quick assessment.
Interfaces
Interfaces
LX218 has a wide variety of interfaces and
connections to expand its capabilities.
Different leak testing methods
Different leak testing methods
Suitable for every application.


LINXON LX218 Accessories:

Remote Control
Remote Control
Compatiblity to INFICON RC1000 for wireless
operation.
Sniffer line 3, 5, 10 m
Sniffer line 3, 5, 10 m
For the sniffing leak testing method.



ORDER INFORMATION BASIC UNIT

LINXON LX218 WET
230V 50Hz version
115V 60Hz version
100V 60Hz version
LINXON LX218 DRY
230V 50Hz version
115V 60Hz version
LINXON LX218 MODULE
100V-250V 50/60 Hz

8200-000
8200-001
8200-005

8200-002
8200-003

8200-004

TECHNICAL DATA

Lowest detectable leak rate for He (according to AVS 2.1)
< 5 x 10-13 Pa m3/s
Ion source
Two long-life iridium filaments, yttrium-oxide coated (three-year warranty)
Testing method
Vacuum and sniffer leak detection
Detectable gases
4He, 3He, H2
Internal He test leak
10-8 Pa m3/s
Leak rate display
10-13 - 0.1 Pa m3/s
Time to operation
3 min.
Response time
0.5 s
Suction capacity: He
2.5 l/s
Connecting flange
DN 25 ISO-KF
Inlet pressure, max.
25 mbar
Ambient temperature
+10°C to +35°C in operation
Input: analog
Compact gauge
Input: digital
Start/stop, zero, calibration
Interface
RS-232-C, RS-485
Output: analog
Leak rate signal 2 x 0-10 V, lin/log
Output: digital
Ready to start, ready to measure, leak, error, partial flow valve
Relay: switch voltage
2 x 230 V AC
Relay: switch current
3 A

ORDER INFORMATION ACCESSOIRES

Sniffer line 3m
551-300
Sniffer line 5m
551-301
Sniffer line 10m
551-302
Remote control with cable (INFICON RC1000)
551-010
Remote control wireless (INFICON RC1000)
551-015


Linxon LX218


LINXON LX218 Videos:









LINXON LX218 Documentation:

Manuals & Brochures
LX218_Brochure_EN
LX218_Brochure_ZH
LX218-Operation-Manual-EN
LX218-Operation-Manual-ZH
LX218-INSTRUKCII-PO-EHKSPLUATACII-RU
LX218-Protocol-Description-EN
